From a small socket to a home battery: this overview brings together the photovoltaic range of Energie24.Shop. It is a good starting point if you want to get an overview.
Pulsar Plus is the smallest powerful EV charging station from Wallbox. It fits anywhere and changes colour depending on the charging status, so you can see at a glance whether your car is still charging or ready to go. It is available with a variety of charging cables and current ratings and can therefore charge any electric car at up to 22 kW.
The myWallbox app makes home charging even easier. It lets you manage your charging station from any smart device via Wi-Fi and Bluetooth. You can control charging sessions, create schedules, receive notifications and much more. With Pulsar Plus you stay in control of thecharging process and set off every morning with a full battery.
This kit contains:
1x Pulsar Max
1x Wallbox 1-phase electricity meter
1x cable holder
Pulsar Max retains the advanced performance of the Pulsar family while introducing a future-proof design for greater robustness and ease of use.
IK10 protection rating with a scratch-resistant, matt texture.
Ultra-fast advanced CPU:
Higher processing speeds for better connectivity and future-proof readiness for security updates – purpose-built for charging.
Backplate for easy installation: Reduce installation time by 10 - 20% with an easy-to-mount design.
Compatible with solar charging
Use Eco-Smart – and all Wallbox energy management solutions – to maximise cost and energy savings.
1-phase electricity meter: Combining an energy meter with your smart charger activates the Power Boost function.
This kit contains:
1x Pulsar Max
1x Wallbox 3-phase electricity meter
1x cable holder
Pulsar Max retains the advanced performance of the Pulsar family while introducing a future-proof design for greater robustness and ease of use.
IK10 protection rating with a scratch-resistant, matt texture.
Ultra-fast, advanced CPU:
Higher processing speeds for better connectivity
and future-proof readiness for security updates – purpose-built for charging.
Backplate for easy installation
Reduce installation time by 10 – 20% with an easy-to-mount design.
Compatible with solar charging
Use Eco-Smart – and all Wallbox energy management solutions – to maximise cost and energy savings.
3-phase electricity meter
Get an electricity meter and keep control of your electricity bills
Combining an energy meter with your smart charger activates the Power Boost function.
The Wallbox Kit Pulsar Max PLP2 offers a powerful 22 kW charging solution with a permanently attached 5 m Type 2 cable in elegant black. The integrated three-phase power meter enables smart control and PV surplus charging. The compact design, robust IP55 protection rating and dock holder make the kit ideal for indoor and outdoor use. Thanks to Wi-Fi and Bluetooth connectivity, the wallbox can be conveniently operated via app. With features such as Eco-Smart and Power Boost, you can optimise your charging management efficiently.
22 kW (3-phase) charging power with Type 2 connector
5 m Type 2 cable, black, including dock holder
Integrated energy management functions via power meter & app
This kit combines state-of-the-art charging technology with smart energy management and ensures efficient, safe and comfortable charging of your electric car.
Scope of delivery: 1x Wallbox Pulsar Max (22 kW / 5 m Type 2 cable / black), 1x power meter (3-phase), 1x dock
The Growatt MID 40KTL3-X is a three-phase string inverter with 40000 W AC rated power and four MPP trackers. It is transformerless and designed for commercial and larger residential rooftop systems.
Highlights
Four MPP trackers: 2 strings per tracker with up to 26 A input current.
Efficiency: Maximum 98.8%, European efficiency 98.5%.
AFCI: Integrated arc detection, to be activated after installation.
Surge protection: Type II on the DC and AC side.
Operation: Touch button and OLED display; RS485 and USB, Wi-Fi, GPRS, RF or LAN optional.
Housing: IP66, intelligent cooling.
Technical specifications
Description
Value
AC rated power
40000 W
Max. AC apparent power
44000 VA
Max. PV power (STC)
60000 W
Max. input voltage
1100 V
Start-up voltage
250 V
MPPT voltage range
200–1000 V
Max. output current
66.6 A
Max. efficiency
98.8%
Operating temperature
-35 to +60 °C
Dimensions (W x H x D)
580 x 435 x 230 mm
Weight
30.5 kg
Warranty
5 years (optional 10 years)
Scope of delivery
1× Growatt 3PH inverter MID 40KTL3-X (without smart meter)
Who is it for?
For commercial roofs, agriculture and larger systems with a three-phase grid connection.
Good to know
The inverter is supplied without a smart meter. Connection and commissioning must be carried out by a qualified electrician; registration with the grid operator and in the Marktstammdatenregister (German market master data register, MaStR) is the operator's responsibility.
We will gladly advise you personally on selection and use: by phone on +49 931 760 260 40 or by e-mail at kontakt@energie24.shop.
The Growatt MID 33KTL3-X inverter is part of the MID series, a series of three-phase Growatt inverters with a lighter and more compact design than their predecessors.
Growatt MID 33KTL3-X 33 kW
The Growatt MID 33KTL3-X 33 kW inverter has a maximum output power of 33,000 W. This device is compatible with systems up to a maximum size of 49.5 kWp. The inverter's maximum efficiency is measured at a maximum conversion efficiency of 98.5%. This efficiency applies to average weather conditions in Europe.
Features MID 33KTL3-X
The maximum output of the MID 33KTL3-X is supported by 3 MPP trackers. The inverter is supplied without a smart meter and can be used for self-supply or grid feed-in.
Safety
To ensure the safety of the system, the Growatt MID 33KTL3-X is equipped with the following integrated protective measures:
DC disconnect switch
DC and AC surge protection, type 2
AFCI protection
Protection class 66
This inverter communicates with other devices in the network via the following interfaces:
RS485
USB
WiFi (optional)
GPRS (optional)
LAN (optional)
The Growatt MAX 80KTL3 LV is a three-phase inverter for commercial PV systems with 80000 W AC rated power and 7 MPP trackers. All models in the series have AFCI protection and string monitoring.
Highlights
7 MPP trackers: 2 strings per tracker, input current up to 26 A.
Efficiency: Maximum 99%, European efficiency 98.5%.
AFCI and monitoring: Arc detection (to be activated after installation) and string monitoring.
Surge protection: Type II on the DC and AC side.
Communication: Local Wi-Fi connection; RS485 and USB, GPRS and RF optional.
Housing: IP65, intelligent cooling.
Technical specifications
Description
Value
AC rated power
80000 W
Max. AC apparent power
88800 VA
Max. PV power (STC)
120000 W
Max. input voltage
1100 V
MPPT voltage range
200–1000 V
Max. input current per tracker
26 A
Max. output current
128.8 A
Max. efficiency
99%
Operating temperature
-25 to +60 °C
Dimensions (W x H x D)
860 x 600 x 300 mm
Weight
86 kg
Warranty
5 years (optional 10 years)
Scope of delivery
1× Growatt 3PH inverter MAX 80KTL3 LV
Who is it for?
For commercial roofs, halls and ground-mounted systems with a three-phase grid connection in the low-voltage range.
Good to know
Connection and commissioning must be carried out by a qualified electrician; registration with the grid operator and in the Marktstammdatenregister (German market master data register, MaStR) is the operator's responsibility.
We will gladly advise you personally on selection and use: by phone on +49 931 760 260 40 or by e-mail at kontakt@energie24.shop.
The Growatt MAX 70KTL3 LV is a three-phase inverter for commercial PV systems with 70000 W AC rated power and 7 MPP trackers. All models in the series have AFCI protection and string monitoring.
Highlights
7 MPP trackers: 2 strings per tracker, input current up to 26 A.
Efficiency: Maximum 99%, European efficiency 98.5%.
AFCI and monitoring: Arc detection (to be activated after installation) and string monitoring.
Surge protection: Type II on the DC and AC side.
Communication: Local Wi-Fi connection; RS485 and USB, GPRS and RF optional.
Housing: IP65, intelligent cooling.
Technical specifications
Description
Value
AC rated power
70000 W
Max. AC apparent power
77700 VA
Max. PV power (STC)
105000 W
Max. input voltage
1100 V
MPPT voltage range
200–1000 V
Max. input current per tracker
26 A
Max. output current
112.7 A
Max. efficiency
99%
Operating temperature
-25 to +60 °C
Dimensions (W x H x D)
860 x 600 x 300 mm
Weight
86 kg
Warranty
5 years (optional 10 years)
Scope of delivery
1× Growatt 3PH inverter MAX 70KTL3 LV
Who is it for?
For commercial roofs, halls and ground-mounted systems with a three-phase grid connection in the low-voltage range.
Good to know
Connection and commissioning must be carried out by a qualified electrician; registration with the grid operator and in the Marktstammdatenregister (German market master data register, MaStR) is the operator's responsibility.
We will gladly advise you personally on selection and use: by phone on +49 931 760 260 40 or by e-mail at kontakt@energie24.shop.
The Growatt MAX 60KTL3 LV is a three-phase inverter for commercial PV systems with 60000 W AC rated power and 6 MPP trackers. All models in the series have AFCI protection and string monitoring.
Highlights
6 MPP trackers: 2 strings per tracker, input current up to 26 A.
Efficiency: Maximum 98.8%, European efficiency 98.4%.
AFCI and monitoring: Arc detection (to be activated after installation) and string monitoring.
Surge protection: Type II on the DC and AC side.
Communication: Local Wi-Fi connection; RS485 and USB, GPRS and RF optional.
Housing: IP65, intelligent cooling.
Technical specifications
Description
Value
AC rated power
60000 W
Max. AC apparent power
66600 VA
Max. PV power (STC)
90000 W
Max. input voltage
1100 V
MPPT voltage range
200–1000 V
Max. input current per tracker
26 A
Max. output current
96.6 A
Max. efficiency
98.8%
Operating temperature
-25 to +60 °C
Dimensions (W x H x D)
860 x 600 x 300 mm
Weight
82 kg
Warranty
5 years (optional 10 years)
Scope of delivery
1× Growatt 3PH inverter MAX 60KTL3 LV
Who is it for?
For commercial roofs, halls and ground-mounted systems with a three-phase grid connection in the low-voltage range.
Good to know
Connection and commissioning must be carried out by a qualified electrician; registration with the grid operator and in the Marktstammdatenregister (German market master data register, MaStR) is the operator's responsibility.
We will gladly advise you personally on selection and use: by phone on +49 931 760 260 40 or by e-mail at kontakt@energie24.shop.
The Growatt MAX 120KTL3-X LV is a three-phase inverter for large commercial PV systems with 120000 W AC rated power and 10 MPP trackers in a fuse-free design.
Highlights
10 MPP trackers: 2 strings per tracker with up to 32 A input current.
Efficiency: Maximum 98.8%, European efficiency 98.5%.
Diagnostics: Intelligent I/V scan and string monitoring.
Safety: AFCI, anti-PID function and type II surge protection on the AC and DC side.
Housing: IP66, intelligent cooling.
Communication: RS485 and USB; PLC, GPRS, 4G and Wi-Fi optional.
Technical specifications
Description
Value
AC rated power
120000 W
Max. AC apparent power
132000 VA
Max. DC voltage
1100 V
Start-up voltage
195 V
MPPT voltage range
180–1000 V
Max. output current at 400 V
190.5 A
Max. efficiency
98.8%
Operating temperature
-30 to +60 °C
Dimensions (W x H x D)
970 x 640 x 345 mm
Weight
84 kg
Night-time consumption
< 1 W
Warranty
5 years (optional 10 years)
Scope of delivery
1× Growatt 3PH inverter MAX 120KTL3-X LV
Who is it for?
For commercial, industrial and ground-mounted sites with high system output on the low-voltage grid.
Good to know
Systems of this size generally require coordination with the grid operator. Connection and commissioning must be carried out by a qualified electrician; registration with the grid operator and in the Marktstammdatenregister (German market master data register, MaStR) is the operator's responsibility.
We will gladly advise you personally on selection and use: by phone on +49 931 760 260 40 or by e-mail at kontakt@energie24.shop.
The Growatt MAX 110KTL3-X LV is a three-phase inverter for large commercial PV systems with 110000 W AC rated power and 10 MPP trackers in a fuse-free design.
Highlights
10 MPP trackers: 2 strings per tracker with up to 32 A input current.
Efficiency: Maximum 98.8%, European efficiency 98.5%.
Diagnostics: Intelligent I/V scan and string monitoring.
Safety: AFCI, anti-PID function and type II surge protection on the AC and DC side.
Housing: IP66, intelligent cooling.
Communication: RS485 and USB; PLC, GPRS, 4G and Wi-Fi optional.
Technical specifications
Description
Value
AC rated power
110000 W
Max. AC apparent power
121000 VA
Max. DC voltage
1100 V
Start-up voltage
195 V
MPPT voltage range
180–1000 V
Max. output current at 400 V
174.6 A
Max. efficiency
98.8%
Operating temperature
-30 to +60 °C
Dimensions (W x H x D)
970 x 640 x 345 mm
Weight
84 kg
Night-time consumption
< 1 W
Warranty
5 years (optional 10 years)
Scope of delivery
1× Growatt 3PH inverter MAX 110KTL3-X LV
Who is it for?
For commercial, industrial and ground-mounted sites with high system output on the low-voltage grid.
Good to know
Systems of this size generally require coordination with the grid operator. Connection and commissioning must be carried out by a qualified electrician; registration with the grid operator and in the Marktstammdatenregister (German market master data register, MaStR) is the operator's responsibility.
We will gladly advise you personally on selection and use: by phone on +49 931 760 260 40 or by e-mail at kontakt@energie24.shop.
The Growatt SPH8000TL3 BH-UP 3PH hybrid inverter is part of the SPH series BH-UP, a series of inverters that replaces the older series, the SPH series. This new series consists of six models:
SPH4000TL3BH-UP
SPH4600TL3BH-UP
SPH5000TL3BH-UP
SPH6000TL3BH-UP
SPH7000TL3BH-UP
SPH8000TL3BH-UP
SPH10000TL3BH-UP
The Growatt SPH BH series are ideal three-phase hybrid inverters suitable for large residential and small commercial PV systems. The technology these inverters are equipped with guarantees excellent integration of solar systems, storage systems and the power grid, which makes them a popular choice for many installers.
Advantages of the Growatt SPH-BH-UP series
2 MPPTs that allow two rows of solar panels to be connected to the inverter.
Natural cooling that results in less noise.
Easy to use thanks to the integrated LCD screen.
Option to adjust charging and discharging capabilities and times.
Access to the Online Smart Service with an app, OSS system and a web server.
Compatible with the ShineLink-X series for monitoring.
These features make Growatt's SPH-BH-UP series an intelligent and efficient choice for anyone seeking seamless integration of renewable energy technologies.
Growatt SPH8000TL3 BH-UP features
The Growatt SPH8000TL3 BH-UP 3PH hybrid inverter is the second most powerful model in the BH-UP series. This inverter is suitable for solar systems with a maximum output of 12,000 W. The maximum output power of this hybrid inverter is 8 kW. The battery voltage range for home storage is between 100 and 500 V, which makes it compatible with all Growatt HV lithium home storage units.
The Growatt SPH7000TL3 BH-UP 3PH hybrid inverter is part of the SPH BH-UP series, a series of inverters that replaces the older series, the SPH series. This new series consists of six models:
SPH4000TL3BH-UP
SPH4600TL3BH-UP
SPH5000TL3BH-UP
SPH6000TL3BH-UP
SPH7000TL3BH-UP
SPH8000TL3BH-UP
SPH10000TL3BH-UP
The Growatt SPH BH series are ideal three-phase hybrid inverters that are suitable for large residential and small commercial PV systems. The technology these inverters are equipped with guarantees excellent integration of solar systems, storage systems and the power grid, which makes them a popular choice for many installers.
Advantages of the Growatt SPH-BH-UP series
2 MPPTs that allow two solar panel strings to be connected to the inverter.
Natural cooling, which results in less noise.
User-friendliness thanks to an integrated LCD screen.
Option to adjust charging and discharging capacities and times.
Access to the Online Smart Service with an app, OSS system and a web server.
Compatible with the ShineLink-X series for monitoring.
These features make the Growatt SPH-BH-UP series an intelligent and efficient choice for anyone looking for seamless integration of renewable energy technologies.
Growatt SPH7000TL3 BH-UP features
The Growatt SPH7000TL3 BH-UP 3PH hybrid inverter is one of the mid-range models of the BH-UP series. This inverter is suitable for solar systems with a maximum output of 10,500 W. The maximum output power of this hybrid inverter is 7 kW. The battery voltage range for home storage systems is between 100 and 500 V, which makes all Growatt HV lithium home storage systems compatible.
The Growatt SPH5000TL3 BH-UP 3PH hybrid inverter is part of the SPH BH-UP series, a series of inverters that replaces the older series, the SPH series. This new series consists of six models:
SPH4000TL3BH-UP
SPH4600TL3BH-UP
SPH5000TL3BH-UP
SPH6000TL3BH-UP
SPH7000TL3BH-UP
SPH8000TL3BH-UP
SPH10000TL3BH-UP
The Growatt SPH BH series are ideal three-phase hybrid inverters that are suitable for large residential and small commercial PV systems. The technology these inverters are equipped with guarantees excellent integration of solar systems, storage systems and the power grid, which makes them a popular choice for many installers.
Advantages of the Growatt SPH-BH-UP series
2 MPPTs that allow two solar panel strings to be connected to the inverter.
Natural cooling, which results in less noise.
User-friendliness thanks to an integrated LCD screen.
Option to adjust charging and discharging capacities and times.
Access to the Online Smart Service with an app, OSS system and a web server.
Compatible with the ShineLink-X series for monitoring.
These features make the Growatt SPH-BH-UP series an intelligent and efficient choice for anyone looking for seamless integration of renewable energy technologies.
Growatt SPH5000TL3 BH-UP features
The Growatt SPH5000TL3 BH-UP 3PH hybrid inverter is one of the mid-range models of the BH-UP series. This inverter is suitable for solar systems with a maximum output of 7,500 W. The maximum output power of this hybrid inverter is 5 kW. The battery voltage range for home storage systems is between 100 and 500 V, which makes all Growatt HV lithium home storage systems compatible.
The Growatt MID 30KTL3-XH is a three-phase hybrid inverter with 30000 W AC rated power. It is battery-ready and intended for the Growatt APX HV battery system (5–60 kWh).
Highlights
Battery-ready: Battery operating voltage range 600–980 V; two battery connections with max. 25 A each.
MPP trackers: 3 independent trackers with 2 strings each and up to 32 A input current.
Efficiency: Maximum 98.8%, European efficiency 98.5%.
Safety: AFCI protection, Type II surge arresters on the DC and AC side, anti-islanding and residual current monitoring.
DC/AC ratio: Up to 2.
Housing: IP66, intelligent cooling, 31 kg.
Technical specifications
Designation
Value
AC rated power
30000 W
Max. AC operating power
30000 VA
Max. PV power (STC)
60000 W
Max. input voltage
1100 V
MPPT voltage range
160–1000 V
Max. discharge power
30000 W
Max. charging power
15000 W (30000 W with two battery connections)
Max. output current
45.5 A
Max. efficiency
98.8%
Dimensions (W x H x D)
580 x 435 x 230 mm
Weight
31 kg
Warranty
5 years (optionally 10 years)
Scope of delivery
1× Growatt 3PH Hybrid Inverter MID 30KTL3-XH
Who is it for?
For larger residential and commercial properties with a three-phase connection that want to combine PV generation and storage in a single device.
Good to know
Above 20 kW, a 5-year warranty applies, optionally 10 years. Connection and commissioning must be carried out by a qualified electrician; registration with the grid operator and in the Marktstammdatenregister (German market master data register, MaStR) is the operator's responsibility.
We are happy to give you personal advice on selection and use: by phone on +49 931 760 260 40 or by e-mail at kontakt@energie24.shop.
The Growatt MID 25KTL3-XH is a three-phase hybrid inverter with 25000 W AC rated power. It is battery-ready and intended for the Growatt APX HV battery system (5–60 kWh).
Highlights
Battery-ready: Battery operating voltage range 600–980 V; two battery connections with max. 25 A each.
MPP trackers: 3 independent trackers with 2 strings each and up to 32 A input current.
Efficiency: Maximum 98.8%, European efficiency 98.5%.
Safety: AFCI protection, Type II surge arresters on the DC and AC side, anti-islanding and residual current monitoring.
DC/AC ratio: Up to 2.
Housing: IP66, intelligent cooling, 31 kg.
Technical specifications
Designation
Value
AC rated power
25000 W
Max. AC operating power
27500 VA
Max. PV power (STC)
50000 W
Max. input voltage
1100 V
MPPT voltage range
160–1000 V
Max. discharge power
25000 W
Max. charging power
15000 W (30000 W with two battery connections)
Max. output current
41.6 A
Max. efficiency
98.8%
Dimensions (W x H x D)
580 x 435 x 230 mm
Weight
31 kg
Warranty
5 years (optionally 10 years)
Scope of delivery
1× Growatt 3PH Hybrid Inverter MID 25KTL3-XH
Who is it for?
For larger residential and commercial properties with a three-phase connection that want to combine PV generation and storage in a single device.
Good to know
Above 20 kW, a 5-year warranty applies, optionally 10 years. Connection and commissioning must be carried out by a qualified electrician; registration with the grid operator and in the Marktstammdatenregister (German market master data register, MaStR) is the operator's responsibility.
We are happy to give you personal advice on selection and use: by phone on +49 931 760 260 40 or by e-mail at kontakt@energie24.shop.
The Growatt MID 20KTL3-XH hybrid inverter is a popular inverter for residential use. The inverter is suitable for exchanging energy with the power grid and for integrating into a battery system.
The Growatt MID 20KTL3-XH belongs to the MID KTL3-XH series, a series of hybrid inverters that can handle solar systems with an output of 3 to 30 kWp. The MID 20KTL3-XH is one of the more powerful models of the family, but despite its compact size it is a powerhouse with outstanding performance.
Features of the Growatt MID 20KTL3-XH hybrid inverter
The Growatt MID 20KTL3-XH hybrid inverter is equipped with 2 MPP trackers, which ensure optimal performance of the solar modules, even if the array is partially in shade.
The performance of this Growatt inverter series is outstanding: they achieve a maximum efficiency of 98.75% and are thus among the best inverters on the market.
With the IP66 classification, the inverters are protected against all weather conditions. The weight has been limited to 31 kilograms, and thanks to their handy size, the inverters of this Growatt series can also be installed by one person.
If you decide to buy the Growatt MID 20KTL3-XH hybrid inverter in combination with a home battery system, the Growatt APX HV system (5 kWh ~ 60 kWh) works seamlessly with this hybrid inverter.
First consider what you are planning: a balcony power plant (plug-in solar system), a roof system or retrofitting a battery. Then choose panels, inverters and accessories that match each other. The subcategories help you narrow down.
Among other things, we carry solar panels, inverters from Hoymiles, Growatt, SMA, Fronius and Huawei, battery storage from Zendure, Anker and BYD, as well as mounts, cables and wallboxes (EV chargers). The range extends from small parts to complete systems.
For each subcategory you will find tips on choosing. If you are planning a complete system, consider panels, inverter, storage and mount together so that power, voltage and fastening fit together. You will find further answers in our PV and solar FAQ. Grid registration and connection belong in the hands of a qualified electrician.
For personal advice, contact us on +49 931 760 260 40 or by email at kontakt@energie24.shop.
Frequently asked questions
Where do I start?
With a question about your needs: how much electricity do you use, and where should the system go?
Do you also advise on system design?
Yes, by phone or email.
Do I have to register my system?
That depends on the type of system. Inquire with your grid operator and the Bundesnetzagentur (German Federal Network Agency).
