The Victron Mppt 100/50 (MPN SCC020050200) belongs to the big family of bluesolar Mppt Loader And like his big siblings, he also offers ultra-fast power tracking and can thus increase the yield of your solar system. In addition to the larger loading and PV performance, this Blue differentiates even more from the next smaller model, the 100/30.
More protection compared to the smaller models of the Blursolar Mppt series
Compared to the 75/10, 75/15 and 100/15 model, the Bluesolar 100/50 has Mppt Via overheating protection with a switch-off function and automatic recovery after reaching a normal operating temperature. In addition, a PV backstream protection exists from this device in the Blue Mppt Family can be found.
High-speed Mpp-Tracker of the latest generation
Especially when the sky is covered, when the light intensity changes constantly, an extremely faster improves Mppt-Regulator the energy yield compared to PWM charging controls by up to 30 % and compared to slower Mppt-Mear -down by up to 10 %. In addition, the 100/50 has some other innovative technologies such as VE.Direct Communication.
Options for programming, data in real time and display of the course
Modern Apple and Android Smartphones, Tablets, MacBooks and other devices, for example, can be used via VI Ve.direct with the Bluetooth Smart Dongles and the Mppt App or the GX Color Control. Please note the Bluetooth Smart Dongles and GX Color Control Own articles that are not included in the scope of delivery of the charge controller but can be acquired optionally from us.
Essential product features of the Bluesolar 100/50 50a 12V 24V Mppt
- ultra -quick Mpp-Tracker of the latest generation ensures the best possible yield even with a covered sky
- Automatic detection of the Mpp Tension in the case of partial shading ensures further earnings compared to "simpler" Mppt Loader
- Integrated VE.direct data communication sport for connection with additional devices such as Bluetooth Smart Dongle or the GX Color Control Panel
- high maximum efficiency of 98%
- Fully programmable charging algorithms that can later be activated and switched manually via a switch on the housing
- Nominal charging current 50a, 100V maximum PV empty voltage
- 700W maximum PV power at 12V, 1400W at 24V systems
- Integrated protection against battery reolving
- Multi-level and adaptive loading algorithm
- Integrated temperature sensor compensates for conservation and constant charging voltage after temperature
- Day/night-time control and lighting option
Ve.direct data communication sportVe.direct in text mode transmits all important parameters to other devices every second Loader are coupled and thus offers the possibility of communication with additional devices such as the Bluetooth Smart Dongle or the GX Color Control Panel from Victron. The VE.Direct connection is intended for products in which complete canbus integration (VE-Direct) would cause too high costs. You can find more information about Ve.direct in our Victron brand world.
Scope of delivery
1x Victron SCC020050200 Bluesolar Mppt 100/50 12V 24V 50A Loader
Operating instructions
