TRINA

The Trina Solar Vertex S+ 445 Wp is a high-performance bifacial panel that impresses with state-of-the-art technology and an elegant glass-glass construction. With a peak power of 445 Wp and a panel efficiency of 22.3%, this panel is an optimal solution for residential and commercial rooftop systems. Thanks to the bifacial N-type i-TOPCon cell technology, the panel additionally generates energy on the rear side, which significantly increases overall efficiency. Bifacial technology:Thanks to the bifacial cell technology, the Trina Solar Vertex S+ 445 Wp can generate energy from incident light not only on the front but also on the rear side. This can increase the total yield by up to 10%, depending on the installation and environmental conditions. The bifaciality factor is up to 80%, so that the rear side captures light particularly effectively and further optimizes performance. Main features: Peak power of 445 Wp with a panel efficiency of 22.3%, combined with bifacial technology for additional power from the rear side. Bifaciality factor up to 80%: Use light reflections on the rear side for up to 25% higher energy generation. N-type technology: Low degradation – only 1% in the first year and 0.4% in years 2-30, ensuring long-term high performance. Excellent durability: Withstands snow loads of up to 5.4 kPa and wind loads of up to 4 kPa, making the panel particularly resistant to extreme weather conditions. Double-glass technology: Improved fire resistance, longer service life and better recyclability compared to conventional glass-foil panels. Technical details: Panel type: Glass-glass with bifacial rear side (transparent) Rated power (STC): 445 Wp Efficiency: 22.3% Bifaciality factor: up to 10% Front glass: 1.6 mm highly transparent, anti-reflective-coated, heat-strengthened glass Rear glass: 1.6 mm highly transparent, anti-reflective-coated, heat-strengthened glass Frame: Sturdy, anodized black aluminum frame Connectors: MC4 EVO2 Dimensions (L x W x H): 1762 mm x 1134 mm x 30 mm Weight: 21.0 kg Product warranty: 25 years Performance warranty: 30-year linear warranty EAN/MPN/GTIN: 4262492210299 The Trina Solar Vertex S+ 445 Wp Bifacial is the ideal choice for modern photovoltaic systems that demand high efficiency. Thanks to the bifacial technology, the full potential of solar irradiation is used, and the robust glass-glass construction ensures maximum durability. Order now and benefit from maximum energy yield and modern design!

Read more Less

Discover the Trina Solar NEG9RC.27, a high-performance solar panel that combines state-of-the-art technology with elegant design. With a peak power of up to 440 Wp and an impressive panel efficiency of 22.0%, this panel is ideal for powerful and aesthetically demanding PV systems. Main features: High performance: With bifacial technology and a bifaciality factor of up to 85%, the panel also generates energy on the rear side, which maximizes overall efficiency. Temperature resistance: The optimized temperature behavior ensures that the panel delivers consistently high performance even at high ambient temperatures. Glass-glass concept: The transparent glass on the rear side not only increases stability but also gives the panel a modern, slim design, perfect for demanding installations. Robust and resilient: The Trina Solar NEG9RC.27 is designed for extreme weather conditions. It withstands snow loads of up to 5,400 Pa and wind loads of up to 4,000 Pa. Thanks to its excellent resistance to fire and adverse environmental influences, this panel is a long-term, reliable investment for your photovoltaic system. Technical details: Power: 440 Wp (0-5 Wp power tolerance) Panel efficiency: 22.0% Dimensions: 1762 mm x 1134 mm Frame color: Black, frame depth of only 30 mm for a slim appearance Cell type: 144 monocrystalline half-cells Weight: 21.0 kg Connection: MC4-EVO2 connector system with 1100 mm cable length Pressure load: Front up to 6,000 Pa, rear up to 4,000 Pa Warranty: 25-year product and performance warranty The Trina Solar NEG9RC.27 combines high-quality materials, innovative technology and exceptional durability – a perfect solution for powerful solar systems that offer not only energy efficiency but also stylish integration into any building.

Read more Less

Trina Vertex S+ TSM-435NEG9RC.27 Bifacial Double-Glass Module Slim design, great power Up to 435 Wp peak power, 21.8% panel efficiency Bifaciality factor up to 85% Better temperature behavior at high ambient temperatures for more power Transparent glass-glass concept Developed with a focus on performance and design Excellent resistance to fire and in difficult environmental conditions 5,400 Pa snow load and 4,000 Pa wind load (test loads) Technical specifications: Manufacturer: Trina Max. recommended DC power: 435 Wp Product name: NEG9RC.27 Panel efficiency: 21.8% Number of cells: 144 Cell type: monocrystalline Cable length: 1100 mm (+) / 1100 mm (-) Connector system: MC4-EVO2 Rear side: Glass (transparent) Frame color: black Frame height: 30 mm Panel width: 1134 mm Panel length: 1762 mm Weight: 21.0 kg Warranty: 25 years Pressure load front: 6000 pa Pressure load rear: 4000 pa Power tolerance (positive): 0-5 Wp

Read more Less
