Solar module - Trina Vertex
S+ TSM-445NEG9RC.27

• Nominal output: 445 WP, with a performance tolerance of +5 Wp.
• Modular type: Monocrystalline's double glass module, bifacial
• Bifacial design: This module is bifacial, which means that it can capture sunlight on both sides to generate energy
  increase.
• Back: Transparent
• Cell technology: The module consists of 144 monocrystalline cells, which in a 24 x 6
  Cell configuration are arranged. Trina Vertex technology with
  210 mm half-cells
• Module efficiency: 22,3 %
• Voltage and electricity: The nominal voltage (UMPP) is 44.3 V and the nominal current (IMPP) at 10.05 A. The maximum system voltage is 1500 V.
• Temperature coefficient: The temperature coefficient of ISC is 0.04 %/k, from PMPP -0.3 %/K and
  from UOC -0.29 %/k.
• construction: Glass glass, black frame design
• Efficiency: 22,3 %
• technology: A TopCon technology
• Voltage compatibility: Suitable for high-voltage systems up to 1500V DC
• fitness: Suitable for overhead glazing, high stability
• Thermal behavior: Improved performance at high temperatures
• Cell configuration: The module consists of 144 monocrystalline cells arranged in a 24 x 6 cell configuration.
• Dimensions: It measures 1762 mm in length, 1134 mm in width and 30 mm in height.
• Weight: The module weighs about 21 kg.
• Connection type: It uses the MC4 EVO 2 connection system.
• Frame and construction: It has a stable, anodized black aluminum frame and a double glass design with a transparent back.
• Guarantee and certification: The product comes with a 25-year performance guarantee and is PID-free. It also has CE certification.
