Growatt Smart Meter TPM-CT-E (3PH) -3x CT 250A

Description

The Growatt Smart Meter TPM-CT-E is a three-phase electricity meter with three current transformers for 250 A. It is used to record consumption and grid import, for example for feed-in limitation with inverters of the Growatt WIT series.

Highlights

  • Measurement accuracy: Class 0.5S; accuracy 0.2% for voltage and current, 0.5% for power.
  • Three-phase: For grids with 3P3W and 3P4W.
  • Three current transformers: For easy installation, measurement of up to 250 A.
  • Communication: RS485 with Modbus RTU and 9600 baud.
  • Operation: LCD display for easy setting and checking.
  • Mounting: On 35-mm DIN rail.

Technical specifications

Description Value
Grid type 3P3W / 3P4W
Input voltage 3P3W (L-L) 173–480 VAC
Input voltage 3P4W (L-N) 100–276 VAC
Frequency 50/60 Hz
Max. detection current of the current transformers 250 A
Inner dimension of the current transformers 30 x 20 mm
Interface RS485 (Modbus RTU, 9600 baud)
Protection rating IP51
Operating temperature -25 to +55 °C
Dimensions (W x D x H) 94.5 x 72 x 65 mm
Weight 220 g

Scope of delivery

  • 1× Growatt Smart Meter TPM-CT-E-EU (250 A)
  • 3 current transformers (250 A) and RS485 cable (15 m) according to the data sheet

Who is it for?

For operators of three-phase Growatt systems who want to measure grid import and feed-in or implement feed-in limitation.

Good to know

According to the data sheet, the meter is compatible with Growatt WIT inverters; for other models, please ask us beforehand. Installation should be left to a qualified electrician.

We will gladly advise you personally on selection and use: by phone on +49 931 760 260 40 or by e-mail at kontakt@energie24.shop.
